Description
Features:
· 1/2.8″ high quality image sensor, 2.07 million effective pixels, maximum resolution up to 1920 x 1080.
· f=4.3mm～129mm focal length, F1.6～F4.7 aperture.
· 30x optical zoom, 10x electronic zoom lens, viewing angle range of 62.76 °. 3.
· Horizontal rotation angle of -170°～+170°, elevation angle of -30°～+30°.
· Support 8000, 16000, 32000, 44100, 48000 sampling frequency.
· Support AAC, MP3, G.711A audio coding;
· Low power consumption hibernation function.
· Support DVI (HDMI), HDMI, SDI, USB2.0, USB3.0, wired LAN audio and video output options.
· Support H.264+/H.264 video compression.
· Support AAC, MP3, PCM audio compression.
· Support ONVIF, GB/T28181, RTSP, RTMP protocols.
· Support PTZ automatic flip function.
· Support VISCA, PELCO-D, PELCO-P protocol.
· RS-485 control and RS-232 cascade.
Schematic of the venue：
Accessories：
HY-CK100— Camera Control Keypad
